Z3 - SGROSSATURA

Diametro

HRc

L1 L.Utile

L3 L.Scarico

D2 D.Gambo

Raggio

Codice	Descrizione	Diametro	HRc	L2	L1 L.Utile	L3 L.Scarico	D2 D.Gambo	Raggio
PK503
12372503	PK503060 FRESA IN MD 3F D6,0/9/57/6	6	Fino a 55	57	9		6
12371353	PK503080 FRESA IN MD 3F D8,0/12/63/8	8	Fino a 55	63	12		8
12370122	PK503100 FRESA IN MD 3F D10,0/15/72/10	10	Fino a 55	72	15		10
12371272	PK503120 FRESA IN MD 3F D12,0/18/83/12	12	Fino a 55	83	18		12
12374309	PK503140 FRESA IN MD 3F D14,0/21/83/14	14	Fino a 55	83	21		14
12373545	PK503160 FRESA IN MD 3F D16,0/24/92/16	16	Fino a 55	92	24		16
12374443	PK503200 FRESA IN MD 3F D20,0/30/104/20	20	Fino a 55	104	30		20
SF51H
77954651	SF51303002H FRESA IN MD 3F D3,0/8/13/50/6	3	INOX	50	8	13	6	0.2
95765668	SF51304002H FRESA IN MD 3F D4,0/10/15/50/6	4	INOX	50	10	15	6	0.2
UF50
99311796	UF503030 FRESA IN MD 3F D3,0/8/50/6	3	30-50	50	8		6	0.2
58060947	UF503040 FRESA IN MD 3F D4,0/10/50/6	4	30-50	50	10		6	0.2
UF51
80997778	UF513030 FRESA IN MD 3F D3,0/8/50/6	3	30-50	50	8		6
19121506	UF513040 FRESA IN MD 3F D4,0/10/50/6	4	30-50	50	10		6
36932522	UF513050 FRESA IN MD 3F D5,0/13/50/6	5	30-50	50	13		6
14899893	UF513060 FRESA IN MD 3F D6,0/15/60/6	6	30-50	60	15		6
93179977	UF51306020 FRESA IN MD 3F D6,0/20/60/6	6	30-50	60	20		6
10678281	UF513070 FRESA IN MD 3F D7,0/18/70/8	7	30-50	70	18		8
58020227	UF513080 FRESA IN MD 3F D8,0/20/70/8	8	30-50	70	20		8
46300312	UF51308025 FRESA IN MD 3F D8,0/25/70/8	8	30-50	70	25		8
WAF303
12370306	WAF303040 FRESA IN MD 3F D4,0/10/55/6	4	ALU	55	10		6
12373295	WAF303050 FRESA IN MD 3F D5,0/15/55/6	5	ALU	55	15		6
12372130	WAF303060 FRESA IN MD 3F D6,0/16/60/6	6	ALU	60	16		6
12372440	WAF303061 FRESA IN MD 3F D6,0/25/80/6	6	ALU	80	25		6
12372439	WAF303080 FRESA IN MD 3F D8,0/20/65/8	8	ALU	65	20		8
12372373	WAF303081 FRESA IN MD 3F D8,0/30/90/8	8	ALU	90	30		8
12371394	WAF303100 FRESA IN MD 3F D10,0/25/75/10	10	ALU	75	25		10
12371338	WAF303101 FRESA IN MD 3F D10,0/40/100/10	10	ALU	100	40		10
12371144	WAF303120 FRESA IN MD 3F D12,0/30/80/12	12	ALU	80	30		12
12371393	WAF303121 FRESA IN MD 3F D12,0/50/110/12	12	ALU	110	50		12
12375437	WAF303140 FRESA IN MD 3F D14,0/35/90/14	14	ALU	90	35		14
12373162	WAF303160 FRESA IN MD 3F D16,0/42/100/16	16	ALU	100	42		16
12373493	WAF303161 FRESA IN MD 3F D16,0/52/150/16	16	ALU	150	52		16
12374436	WAF303200 FRESA IN MD 3F D20,0/38/104/20	20	ALU	104	38		20
12374260	WAF303201 FRESA IN MD 3F D20,0/55/160/20	20	ALU	160	55		20
