Z5 - Piana

Diametro Lavoro (DL) DC

Numero Taglienti (Z)

Diametro Attacco (dc) DCONS-MS (CIL)

HRc

Lunghezza Utile (l) LE/LU/APMX/LCF

Lunghezza (L) OAL

Angolo/Elica

Codice	Descrizione	Diametro Lavoro (DL) DC	Numero Taglienti (Z)	Diametro Attacco (dc) DCONS-MS (CIL)	HRc	Lunghezza Utile (l) LE/LU/APMX/LCF	Lunghezza (L) OAL	Angolo/Elica	Disp.
- XE505 X-STAR
12372766	XE505060 - X-STAR FRESA IN MD 5F D6,0/13/57/6	6.0	5	6	10-35	13	57	44-45-46
12371677	XE505080 - X-STAR FRESA IN MD 5F D8,0/19/63/8	8.0	5	8	10-35	19	63	44-45-46
12370655	XE505100 - X-STAR FRESA IN MD 5F D10,0/22/72/10	10.0	5	10	10-35	22	72	44-45-46
12371678	XE505120 - X-STAR FRESA IN MD 5F D12,0/26/83/12	12.0	5	12	10-35	26	83	44-45-46
12374933	XE505140 - X-STAR FRESA IN MD 5F D14,0/26/83/14	14.0	5	14	10-35	26	83	44-45-46
12373888	XE505160 - X-STAR FRESA IN MD 5F D16,0/32/92/16	16.0	5	16	10-35	32	92	44-45-46
68292923	XE505180 - X-STAR FRESA IN MD 5F D18,0/32/92/18	18.0	5	18	10-35	32	92	44-45-46
12374934	XE505200 - X-STAR FRESA IN MD 5F D20,0/38/104/20	20.0	5	20	10-35	38	104	44-45-46
15322158	XE505250 - X-STAR FRESA IN MD 5F D25,0/38/104/25	25.0	5	25	10-35	38	104	44-45-46
- XE515 X-STAR
12372839	XE515060 - X-STAR FRESA IN MD 5F D6,0/25/75/6	6.0	5	6	10-35	25	75	45
12371734	XE515080 - X-STAR FRESA IN MD 5F D8,0/30/75/8	8.0	5	8	10-35	30	75	45
12371735	XE515100 - X-STAR FRESA IN MD 5F D10,0/45/100/10	10.0	5	10	10-35	45	100	45
12371736	XE515120 - X-STAR FRESA IN MD 5F D12,0/75/150/12	12.0	5	12	10-35	75	150	45
12373891	XE515160 - X-STAR FRESA IN MD 5F D16,0/75/150/16	16.0	5	16	10-35	75	150	45
12374936	XE515200 - X-STAR FRESA IN MD 5F D20,0/75/150/20	20.0	5	20	10-35	75	150	45
